WisGate Developer D4+

  • Frequency band

SG$ 424.89 SG$ 424.89 424.89 SGD

US$ 316.00

This combination does not exist.

Add to Cart

5.5V module Radial lead shrink wrap 3.5F


Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Rakwireless

RAKwireless is an industrial-leading connectivity provider that builds infrastructures and Modular Edge devices for IoT, Smart City, and Smart Agriculture markets with in-house developed solutions, utilizing LPWA (Low Power Wide Area) technologies.


Do something

Overview

The WisGate Developer D4 (RAK7244) is a successor of WisGate Developer D3 (RAK7243). This device consists of a Raspberry Pi 4, a RAK2245 Pi HAT, which includes a GPS module and a Heat Sink for better performance and thermal heat dissipation management, and an optional RAK2013 Cellular Pi HAT. Its housing is entirely built from aluminum.


The built-in RAK2245 Pi HAT uses the SX1301 RF front-end chip from Semtech, which is a powerful LoRa® digital processing engine. It is able to receive up to 8 LoRa® packets simultaneously sent with different spreading factors on different channels and available in multiple variants so it can be used for all LoRa Alliance® frequency bands. This unique capability allows for innovative network architectures to be implemented, which is advantageous over other short-range systems. The built-in RAK2013 Cellular Pi HAT is based on the EG95 from Quectel, which is an LTE CAT4 module optimized specifically for M2M and IoT applications.


WisGate Developer D4 is a Class A and C compliant that is ideal for prototyping, proof-of-concept demonstrations or for the evaluation of future deployment scenarios. It includes a ready-to-use Firmware based on Raspbian OS, which makes it possible to connect the Gateway to any standard LoRaWAN® Server. It is developer-friendly as the large Raspbian OS community is a well-established one. It is especially suited to addressing a variety of applications like Smart Grids, Intelligent Farms, and other IoT Enterprise applications.


Features

  • Refreshed Case design with a new MCU (Raspberry Pi4)

  • Preassembled, fully functioning LPWAN developer gateway

  • Full LoRaWAN® Stack support (version 1.0.2)

  • Supports for 8 channels and spreading factors (SF7-SF12)

  • Band support: 433MHz, 470MHz, 865MHz, 868MHz, 915MHz, 920MHz, 923MHz

  • TX power up to 27dBm

  • RX Sensitivity: -139dBm

  • Integrates Ublox MAX-7Q GPS module

  • Quectel EG95 LTE module


Specifications for WisGate Developer D4+

Frequency band AS923 or AU915 or EU868 or IN865 or US915
