Waterproof Long Range Wireless Version 2 LoRa Sensor Node

  • LoRa transceiver
  • Cable length
  • Frequency band
  • OpenCPU
  • Power type
  • LoRaWAN version
  • Battery Capacity

SG$ 60.51 SG$ 60.51 60.51 SGD

US$ 45.00

This combination does not exist.

Add to Cart

LSN50 is an open source product, it is based on the STM32Cube HAL drivers and lots of libraries can be found in ST site for rapid development.
1 x LSN50 v2 module
1 x External RF antenna


Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Dragino


We focus on the Internet of Things industry and keep evaluating new technology on improving user experience in IoT solution. We provide OEM/ODM service to worldwide clients. We have a set of offshore products and development kits to help clients to test, design and produce innovation IoT products in the shorter time, lower cost and lowest risk. Dragino dedicates to promote Open Source IoT solution. Our Open Source products are sold world widely and gain good name in the Open Source Internet of Things filed.


More Detail

Overview

LSN50 LoRa Sensor Node is a Long Range LoRa Sensor Node. It is designed for outdoor use and powered by 4000mA or 8500mA Li/SOCl2 battery for long term use.LSN50 is designed to facilitate developers to quickly deploy industrial level LoRa and IoT solutions. It help users to turn the idea into a practical application and make the Internet of Things a reality. It is easy to program, create and connect your things everywhere.

LSN50 is an open source product, it is based on the STM32Cube HAL drivers and lots of libraries can be found in ST site for rapid development.

Features

  • STM32L072CZT6 MCU

  • SX1276/78 LoRa Wireless Modem

  • Pre-load with ISP bootloader

  • I2C,LPUSART1,USB

  • 18 x Digital I/Os

  • 2 x 12bit ADC; 1 x 12bit DAC

  • MCU wake up by UART or Interrupt

  • LoRa™ Modem

  • Preamble detection

  • Baud rate configurable

  • LoRaWAN 1.0.2 Specification

  • Software base on STM32Cube HAL drivers

  • Open source hardware / software

  • Available Band:433/868/915/920 Mhz

  • IP68 Waterproof Enclosure

  • Ultra Low Power consumption

  • AT Commands to setup parameters

  • 4000mAh or 8500mAh Battery for Long term use

Applications

Specifications for Waterproof Long Range Wireless Version 2 LoRa Sensor Node

LoRaWAN
LoRa transceiver SX1276
Uncategorized
Cable length No Hole or M12 or M16
Battery Capacity 4000mAh or 8500mA
Frequency band AS923
OpenCPU Yes
Power type Battery
LoRaWAN version 1.0.2
