LoRaWAN NEMA Lamp Controller

  • Configuration Interface
  • Cable length
  • Sensor
  • Waterproof
  • Class
  • Frequency band
  • Power type
  • Sensor Measurement Range

SG$ 101.18 SG$ 101.18 101.18 SGD

US$ 76.90

This combination does not exist.

Add to Cart

Support NEMA and standard LoRaWAN Class C


Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Winext

About us. Winext Technology is an AIoT "end-to-end" one-stop solution provider. Focusing on R&D for IoT, we offer whole stack IoT products and system solutions. Our business covers smart city, smart community, smart firefighting, smart elevator, smart street lighting, smart parking and so on


Do something

Overview


WLC-NEMA-03 NEMA interface single lamp controller adopts LoRa narrowband Internet of Things communication technology. It is a high-performance street lamp energy-saving product specially developed for smart street lighting. The single lamp controller realizes the monitoring and collection of the voltage, current, power, electric energy and other load working parameters of a single street lamp, and has functions such as controlling the street lamp switch and dimming. The product has electronic protection functions such as overload and short circuit protection, IP65 protection level, and can be used in harsh environments. Single-lamp controllers are widely used in tunnel lighting, urban road lighting, landscape lighting, etc.

Features


  • Integrated standard LoRaWAN communication protocol

  • It has the function of collecting data such as current, voltage, power and electric energy of street lights

  • With the function of proactively reporting fault information

  • With remote turn on, turn off and dimming functions

  • 1 PWM or 0~10V dimming output

  • IP65 protection level, can be used in harsh environments

  • Electronic protection functions such as overload and short circuit protection

  • Perceive light and dark changes, support automatic adjustment of street lamp brightness

Specifications for LoRaWAN NEMA Lamp Controller

LoRaWAN
Configuration Interface UART
Uncategorized
Sensor with Photo cell or without photo cell
Frequency band AS923 or AU915 or KR920 or US915
Cable length NA
Waterproof IP68
Class Class C
Power type NEMA Socket
Sensor Measurement Range NA
